Amplifier Section

Power Output
Front
L/R 100 W/Ch (6, 1 kHz, 1% THD,1 Channel Driven, IEC)
120 W/Ch (6, 1 kHz, 1 Channel Driven, JEITA)
Center
100 W (6, 1 kHz, 1% THD, 1 Channel Driven, IEC)
120 W (6, 1 kHz, 1 Channel Driven, JEITA)
Surround
L/R 100 W/Ch (6, 1 kHz, 1% THD,1 Channel Driven, IEC)
120 W/Ch (6, 1 kHz, 1 Channel Driven, JEITA)

Dynamic Power
160 W (3, Front)
125 W (4, Front)
85 W (8, Front)

THD+N (Total Harmonic Distortion + Noise)
0.08% (20 Hz–20 kHz, Half Power)
Damping Factor
60 (Front, 1 kHz, 8)
Input Sensitivity and Impedance
200 mV/47 (Line)
Rated RCA Output Level and Impedance
200 mV/2.2 k (Rec Out)
Maximum RCA Output Level and Impedance
2.0 V/2.2 k (Rec Out)
Frequency Response
5 Hz–100 kHz/+1 dB, -3 dB (DSP Bypass)
Tone Control
10 dB, 50 Hz (Bass)
10 dB, 20 kHz (Treble)
Signal-to-Noise Ratio
100 dB (Line, IHF-A)
Speaker Impedance
6 – 16

Video Section

Input Sensitivity/Output Level and Impedance
Video
1.0 Vp–p/75 (Component)
0.7 Vp–p/75 (Component PB/CB, PR/CR)
1.0 Vp–p/75 (Composite)
Component Video Frequency Response
5 Hz–100 MHz/+0 dB, -3 dB

Tuner Section

Tuning Frequency Range
FM 87.5 MHz–108 MHz
AM 522 kHz–1,611 kHz
530 kHz–1,710 kHz
FM/AM Preset Memory
40 Stations

General

Power Supply
AC 230 V~, 50/60 Hz
(Asian Model: AC 220–240 V~, 50/60 Hz)
Power Consumption
300 W (Asian Model: 340 W)
Dimensions
(W x H x D) 435 x 150 x 318 mm
Weight
7.6 kg

CARTON

Dimensions
(W x H x D) 537 x 268 x 416 mm
Weight
9.6 kg (Asian Model: 9.8 kg)
Supplied Accessories
• Indoor FM antenna
• AM loop antenna
• Speaker cable labels
• Instruction manual
• Quick start guide
• Remote controller
• AA (R6) batteries* x 2
